Spiral Fluted Taps

Intro TCTR Ø Hole Ø Code THCHT LF LT THL LU LS DCON K LK NOF Type Stock
M (tolerance) (mm) (mm) (chamfer) (mm) (mm) (mm) (mm) (mm) (mm) (mm) (mm)
JIS
P3 21 21.13 SUMR024S 2.5P 120 - 39 - 55 19 15 18 4 013 f
SP M24X3 P4(P3+20) 21 21.13 SUMS024S 2.5P 120 - 39 - 55 19 15 18 4 013 f
P5(P3+40) 21 21.13 SUMT024S 2.5P 120 - 39 - 55 19 15 18 4 013 f
JIS
P3 24 24.13 SUMR027S 2.5P 130 - 39 - 60 20 15 18 4 013 f
M27X3
P4 26.5 26.63 SUMS030T 2.5P 135 - 46 - 62 23 17 20 4 013 f
M30X3.5
SL
M33X3.5 P4 29.5 29.63 SUMS033T 2.5P 145 - 46 - 67 25 19 22 4 013 f
P4 32 32.12 SUMS036U 2.5P 155 - 52 - 71 28 21 24 4 013 f
M36X4
P4 35 35.12 SUMS039U 2.5P 165 - 52 - 76 30 23 26 4 013 f
M39X4
PO M42X4.5 P4 37.5 37.63 SUMS042V 2.5P 175 - 59 - 81 32 26 30 4 013 f
P4 40.5 40.63 SUMS045V 2.5P 180 - 59 - 83 35 26 30 4 013 f
M45X4.5
P4 43 43.12 SUMS048W 2.5P 185 - 65 - 85 38 29 32 4 013 f
M48X5
TCTR Ø Hole Ø Code THCHT LF LT THL LU LS DCON K LK NOF Type Stock
ST MF (tolerance) (mm) (mm) (chamfer) (mm) (mm) (mm) (mm) (mm) (mm) (mm) (mm)
JIS
P2 5.3 5.33 SUMQ6.0J 2.5P 62 - 15 26 33 6 4.5 7 3 001 f
M6X0.75
P2 7 7.09 SUMQ8.0M 2.5P 70 - 19 - 36 6.2 5 8 3 013 f
M8X1
ROLL
M8X0.75 P2 7.3 7.33 SUMQ8.0J 2.5P 70 - 19 - 36 6.2 5 8 3 013 f
P2 8.8 8.85 SUMQ010N 2.5P 75 - 23 - 38 7 5.5 8 3 013 f
P3(P2+20) 8.8 8.85 SUMR010N 2.5P 75 - 23 - 38 7 5.5 8 3 013 f
M10X1.25
CARBIDE P4(P2+40) 8.8 8.85 SUMS010N 2.5P 75 - 23 - 38 7 5.5 8 3 013 f
P2 9 9.09 SUMQ010M 2.5P 75 - 23 - 38 7 5.5 8 3 013 f
P4(P2+40) 9 9.09 SUMS010M 2.5P 75 - 23 - 38 7 5.5 8 3 013 f
M10X1
P2 10.5 10.6 SUMQ012O 2.5P 82 - 26 - 42 8.5 6.5 9 3 013 f
LONG P3(P2+20) 10.5 10.6 SUMR012O 2.5P 82 - 26 - 42 8.5 6.5 9 3 013 f
M12X1.5
P4(P2+40) 10.5 10.6 SUMS012O 2.5P 82 - 26 - 42 8.5 6.5 9 3 013 f
P2 10.8 10.85 SUMQ012N 2.5P 82 - 26 - 42 8.5 6.5 9 3 013 f
HAND M12X1.25 P3(P2+20) 10.8 10.85 SUMR012N 2.5P 82 - 26 - 42 8.5 6.5 9 3 013 f
TAPS M12X1 P2 11 11.09 SUMQ012M 2.5P 82 - 26 - 42 8.5 6.5 9 3 013 f
P2 12.5 12.6 SUMQ014O 2.5P 88 - 26 - 45 10.5 8 11 3 013 f
M14X1.5
P4(P2+40) 12.5 12.6 SUMS014O 2.5P 88 - 26 - 45 10.5 8 11 3 013 f
EG (STI) M14X1 P2 13 13.09 SUMQ014M 2.5P 88 - 26 - 45 10.5 8 11 3 013 f
P2 14.5 14.6 SUMQ016O 2.5P 95 - 26 - 48 12.5 10 13 3 013 f
M16X1.5
P4(P2+40) 14.5 14.6 SUMS016O 2.5P 95 - 26 - 48 12.5 10 13 3 013 f
SPECIAL P2 16.5 16.6 SUMQ018O 2.5P 100 - 33 - 51 14 11 14 4 013 f
THREADS, M18X1.5 P4(P2+40) 16.5 16.6 SUMS018O 2.5P 100 - 33 - 51 14 11 14 4 013 f
GAUGES
P3 18.5 18.6 SUMR020O 2.5P 105 - 33 - 50 15 12 15 4 013 f
M20X1.5
P4(P3+20) 18.5 18.6 SUMS020O 2.5P 105 - 33 - 50 15 12 15 4 013 f
THREAD P3 20.5 20.6 SUMR022O 2.5P 115 - 33 - 55 17 13 16 4 013 f
MILLS M22X1.5 P4(P3+20) 20.5 20.6 SUMS022O 2.5P 115 - 33 - 55 17 13 16 4 013 f
P3 22 22.12 SUMR024Q 2.5P 120 - 39 - 55 19 15 18 4 013 f
M24X2
P3 22.5 22.6 SUMR024O 2.5P 120 - 39 - 55 19 15 18 4 013 f
DIES M24X1.5 P4(P3+20) 22.5 22.6 SUMS024O 2.5P 120 - 39 - 55 19 15 18 4 013 f
P3 25.5 25.6 SUMR027O 2.5P 130 - 39 - 60 20 15 18 4 013 f
M27X1.5
P3 28.5 28.6 SUMR030O 2.5P 135 - 46 - 62 23 17 20 4 013 f
M30X1.5
CENTER M42X1.5 P3 40.5 40.6 SUMR042O 2.5P 175 - 27 - 81 32 26 30 4 013 f
DRILLS

Technical
info
