h stock standard, ) check stock EU, f check stock JP, m stock exhaustion

TCTR Ø Hole Ø Code THCHT LF LT THL LU LS DCON K LK NOF Type Stock Intro
M (tolerance) (mm) (mm) (chamfer) (mm) (mm) (mm) (mm) (mm) (mm) (mm) (mm)
DIN 376
ISO2(6H) 10.3 10.36 SG012PANEXH 3.5P 110 - 26 - 56 9 7 10 3 010 h
M12X1.75
ISO2(6H) 12 12.12 SG014QANEXH 3.5P 110 - 26 - 56 11 9 12 3 010 h SP
M14X2
ISO2(6H) 14 14.12 SG016QANEXH 3.5P 110 - 26 - 56 12 9 12 3 010 h
DIN
M16X2
ISO2(6H) 15.5 15.63 SG018RANEXH 3.5P 125 - 33 - 64 14 11 14 4 010 f
M18X2.5
ISO2(6H) 17.5 17.63 SG020RANEXH 3.5P 140 - 33 - 71 16 12 15 4 010 h
M20X2.5
SL
ISO2(6H) 19.5 19.63 SG022RANEXH 3.5P 140 - 33 - 71 18 14.5 17 4 010 h
M22X2.5
ISO2(6H) 21 21.13 SG024SANEXH 3.5P 160 - 37 - 82 18 14.5 17 4 010 h
M24X3
ISO2(6H) 24 24.13 SG027SANEXH 3.5P 160 - 37 - 82 20 16 19 4 010 f
M27X3
ISO2(6H) 26.5 26.63 SG030TANEXH 3.5P 180 - 44 - 92 22 18 21 4 010 f
M30X3.5 PO
TCTR Ø Hole Ø Code THCHT LF LT THL LU LS DCON K LK NOF Type Stock
MF (tolerance) (mm) (mm) (chamfer) (mm) (mm) (mm) (mm) (mm) (mm) (mm) (mm)
DIN 374
ISO2(6H) 7 7.09 SM8.0MANEXH 3.5P 90 - 19 - 46 6 4.9 8 3 010 h ST
M8X1
ISO2(6H) 8.8 8.85 SM010NANEXH 3.5P 100 - 23 - 51 7 5.5 8 3 010 h
M10X1.25
ISO2(6H) 9 9.09 SM010MANEXH 3.5P 90 - 19 - 46 7 5.5 8 3 010 h
M10X1
ISO2(6H) 10.5 10.6 SM012OANEXH 3.5P 100 - 21 - 51 9 7 10 3 010 h
M12X1.5
ROLL
ISO2(6H) 10.8 10.85 SM012NANEXH 3.5P 100 - 21 - 51 9 7 10 3 010 h
M12X1.25
ISO2(6H) 11 11.09 SM012MANEXH 3.5P 100 - 21 - 51 9 7 10 3 010 h
M12X1
ISO2(6H) 12.5 12.6 SM014OANEXH 3.5P 100 - 21 - 51 11 9 12 3 010 h
M14X1.5
ISO2(6H) 14.5 14.6 SM016OANEXH 3.5P 100 - 21 - 51 12 9 12 3 010 h
M16X1.5 CARBIDE
ISO2(6H) 16.5 16.6 SM018OANEXH 3.5P 110 - 24 - 56 14 11 14 4 010 h
M18X1.5
ISO2(6H) 18 18.12 SM020QANEXH 3.5P 140 - 33 - 71 16 12 15 4 010 f
M20X2
ISO2(6H) 18.5 18.6 SM020OANEXH 3.5P 125 - 24 - 64 16 12 15 4 010 h
M20X1.5
ISO2(6H) 20.5 20.6 SM022OANEXH 3.5P 125 - 24 - 64 18 14.5 17 4 010 h LONG
M22X1.5
ISO2(6H) 22 22.12 SM024QANEXH 3.5P 140 - 27 - 71 18 14.5 17 4 010 h
M24X2
ISO2(6H) 22.5 22.6 SM024OANEXH 3.5P 140 - 27 - 71 18 14.5 17 4 010 h
M24X1.5
ISO2(6H) 23.5 23.6 SM025OANEXH 3.5P 140 - 27 - 71 18 14.5 17 4 010 f HAND
M25X1.5
ISO2(6H) 25 25.12 SM027QANEXH 3.5P 140 - 27 - 71 20 16 19 4 010 h TAPS
M27X2
ISO2(6H) 26.5 26.6 SM028OANEXH 3.5P 140 - 27 - 71 20 16 19 4 010 f
M28X1.5
ISO2(6H) 28 28.12 SM030QANEXH 3.5P 150 - 27 - 77 22 18 21 4 010 f
M30X2
ISO2(6H) 28.5 28.6 SM030OANEXH 3.5P 150 - 27 - 77 22 18 21 4 010 h
M30X1.5 EG (STI)
Basic
TCTR Ø Hole Ø Code THCHT major Ø LF THL LS DCON K LK NOF Type Stock
(tolerance) (mm) (mm) (chamfer) (mm) (mm) (mm) (mm) (mm) (mm)
G(BSP)
(mm)
DIN 5156 SPECIAL
- 8.75 8.78 SVG0020NEXH 3.5P 9.728 90 19 46 7 5.5 8 3 010 h THREADS,
1/8-28
GAUGES
- 11.75 11.78 SVG0040NEXH 3.5P 13.157 100 21 51 11 9 12 3 010 h
1/4-19
- 15.25 15.28 SVG0060NEXH 3.5P 16.662 100 21 51 12 9 12 3 010 h
3/8-19
- 19 19.04 SVG0080NEXH 3.5P 20.955 125 24 64 16 12 15 4 010 h THREAD
1/2-14
- 24.5 24.52 SVG0120NEXH 3.5P 26.441 140 27 71 20 16 19 4 010 h MILLS
3/4-14
- 30.75 30.77 SVG0160NEXH 3.5P 33.249 160 29 82 25 20 23 4 010 f
1 -11
DIES
CENTER
DRILLS
