Spiral Fluted Taps

SP-BLF V
Intro

GP General Purpose Series
SP
Spiral Fluted Taps, Deep Hole Use, Coated
DIN
FEATURES
General purpose for blind hole application.
2.5P
SL HSS-E COATING For tapping steel, also suitable for stainless steel and non-
THCHT ferrous materials application.
BLF geometry reduces edge chipping trouble and
improves chip ejection.
Recommended Tapping Speeds Depending On Materials
PO
ISO Vc (m/min) ISO Vc (m/min) ISO Vc (m/min)
P1 10÷20 + M1 6÷12 , N1 10÷20 ,
P2 10÷20 + N2 10÷20 ,
ST P3 10÷20 + N3 10÷20 ,
P4 10÷15 + N4 10÷20 ,
P7 6÷12 ,
+ 1st choice , suitable
ROLL

DIN-SP-BLF V
TYPE: EU_140 TYPE: EU_025
CARBIDE K
DCON DCON K
LT LK K
THL THL LS LK K
LONG LU LS LU
LF LF

HAND TYPE: EU_023
TAPS DCON K

THL LK K
EG (STI) LS
LF
