Spiral Fluted Taps
LU
LS DCON
K
THL
TCTR
LF
LT
LK
Intro M (tolerance) (mm) Ø Hole Ø Code THCHT (mm) (mm) (mm) (mm) (mm) (mm) (mm) (mm) NOF Type Stock
(chamfer)
(mm)
DIN 376
ISO2X(6HX) 10.3 10.36 3101101088 2.5P 110 - 15 - 56 9 7 10 3 006 h
ISO3X(6GX) 10.3 10.36 3101201088 2.5P 110 - 15 - 56 9 7 10 3 006 h
SP
M12X1.75
7GX 10.3 10.36 3101301088 2.5P 110 - 15 - 56 9 7 10 3 006 h
DIN ISO2X(6HX)+100 10.3 10.36 3101501088 2.5P 110 - 15 - 56 9 7 10 3 006 h
ISO2X(6HX) 12 12.12 3101101100 2.5P 110 - 18 - 56 11 9 12 3 006 h
SL ISO3X(6GX) 12 12.12 3101201100 2.5P 110 - 18 - 56 11 9 12 3 006 h
M14X2
7GX 12 12.12 3101301100 2.5P 110 - 18 - 56 11 9 12 3 006 h
ISO2X(6HX)+100 12 12.12 3101501100 2.5P 110 - 18 - 56 11 9 12 3 006 f
ISO2X(6HX) 14 14.12 3101101114 2.5P 110 - 18 - 56 12 9 12 3 006 h
PO ISO3X(6GX) 14 14.12 3101201114 2.5P 110 - 18 - 56 12 9 12 3 006 h
M16X2
7GX 14 14.12 3101301114 2.5P 110 - 18 - 56 12 9 12 3 006 h
ISO2X(6HX)+100 14 14.12 3101501114 2.5P 110 - 18 - 56 12 9 12 3 006 f
ISO2X(6HX) 15.5 15.63 3101101128 2.5P 125 - 20 - 64 14 11 14 4 006 h
ST M18x2.5
ISO2X(6HX) 17.5 17.63 3101101141 2.5P 140 - 20 - 71 16 12 15 4 006 h
M20x2.5
ISO2X(6HX) 19.5 19.63 3101101156 2.5P 140 - 20 - 71 18 14.5 17 4 006 h
M22x2.5
ISO2X(6HX) 21 21.13 3101101167 2.5P 160 - 25 - 82 18 14.5 17 4 006 h
M24x3
ROLL
TCTR Ø Hole Ø Code THCHT LF LT THL LU LS DCON K LK NOF Type Stock
MF (tolerance) (mm) (mm) (chamfer) (mm) (mm) (mm) (mm) (mm) (mm) (mm) (mm)
DIN 371
ISO2X(6HX) 2.65 2.7 3101101036 2.5P 56 - 5 18 34 3.5 2.7 6 3 004 h
M3X0.35
CARBIDE
ISO2X(6HX) 3.5 3.56 3101101043 2.5P 63 - 5 21 38 4.5 3.4 6 3 004 h
M4X0.5
ISO2X(6HX) 4.5 4.56 3101101051 2.5P 70 - 6 25 39 6 4.9 8 3 004 h
M5X0.5
ISO2X(6HX) 5.25 5.33 3101101056 2.5P 80 - 8 30 45 6 4.9 8 3 004 h
M6X0.75
LONG M6X0.5 ISO2X(6HX) 5.5 5.56 3101101057 2.5P 80 - 8 30 45 6 4.9 8 3 004 h
TCTR Ø Hole Ø Code THCHT LF LT THL LU LS DCON K LK NOF Type Stock
(tolerance) (mm) (mm) (chamfer) (mm) (mm) (mm) (mm) (mm) (mm) (mm) (mm)
MF
DIN 374
HAND ISO2X(6HX) 7 7.09 3101101065 2.5P 90 - 12 - 46 6 4.9 8 3 006 h
TAPS M8X1
ISO2X(6HX) 8.8 8.85 3101101079 2.5P 100 - 13 - 51 7 5.5 8 3 006 h
M10X1.25
ISO2X(6HX) 9 9.09 3101101080 2.5P 90 - 13 - 46 7 5.5 8 3 006 h
M10X1
ISO2X(6HX) 10.5 10.6 3101101089 2.5P 100 - 15 - 51 9 7 10 3 006 h
M12X1.5
EG (STI) ISO2X(6HX) 10.8 10.85 3101101090 2.5P 100 - 15 - 51 9 7 10 3 006 h
M12X1.25
ISO2X(6HX) 12.5 12.6 3101101102 2.5P 100 - 14 - 51 11 9 12 3 006 h
M14X1.5
ISO2X(6HX) 14.5 14.6 3101101116 2.5P 100 - 14 - 51 12 9 12 3 006 h
SPECIAL M16X1.5
THREADS, M18x1.5 ISO2X(6HX) 16.5 16.6 3101101130 2.5P 110 - 14 - 56 14 11 14 3 006 h
GAUGES M20x1.5 ISO2X(6HX) 18.5 18.6 3101101144 2.5P 125 - 14 - 64 16 12 15 3 006 h
ISO2X(6HX) 20.5 20.6 3101101158 2.5P 125 - 14 - 64 18 14.5 17 3 006 h
M22x1.5
ISO2X(6HX) 22.5 22.6 3101101170 2.5P 140 - 18 - 71 18 14.5 17 3 006 h
THREAD M24x1.5
MILLS TCTR Ø Hole Ø THCHT LF LT THL LU LS DCON K LK
(tolerance) (mm) (mm) (chamfer) (mm) (mm) (mm) (mm) (mm) (mm) (mm) (mm)
UNC Code NOF Type Stock
DIN 371
2BX 2.6 2.64 3101103021 2.5P 56 - 5 18 34 3.5 2.7 6 2 004 h
No.5-40UNC
DIES
No.6-32UNC 2BX 2.8 2.83 3101103023 2.5P 56 - 7 19 32 4 3 6 2 004 h
2BX 3.4 3.47 3101103029 2.5P 63 - 7 21 38 4.5 3.4 6 2 004 h
No.8-32UNC
2BX 3.89 3.9 3101103039 2.5P 70 - 9 24 39 6 4.9 8 2 004 h
No.10-24UNC
CENTER 2BX 4.5 4.53 3101103047 2.5P 80 - 9 28 45 6 4.9 8 2 004 h
No.12-24UNC
DRILLS 2BX 5.1 5.19 3101103058 2.5P 80 - 11 30 42 7 5.5 8 2 004 h
1/4-20UNC
2BX 6.6 6.65 3101103071 2.5P 90 - 12 35 47 8 6.2 9 3 005 h
5/16-18UNC
2BX 8 8.07 3101103082 2.5P 100 - 13 39 54 9 7 10 3 005 h
Technical 3/8-16UNC
