Oversized h stock standard, ) check stock EU, f check stock JP, m stock exhaustion

TYPE: VU_004 TYPE: VU_005 Intro
K K
DCON DCON

THL LK K THL LS LK K SP
LU LS LU
LF LF DIN

TYPE: VU_006
SL
K
DCON

THL LK K
LS PO
LF

ST
TCTR Ø Hole Ø Code THCHT LF LT THL LU LS DCON K LK NOF Type Stock
M (tolerance) (mm) (mm) (chamfer) (mm) (mm) (mm) (mm) (mm) (mm) (mm) (mm)
DIN 371
ISO2X(6HX) 1.6 1.65 3101101021 2.5P 45 - 4 10 32 2.8 2.1 5 2 004 h ROLL
M2X0.4
ISO2X(6HX) 1.75 1.81 3101101024 2.5P 45 - 4 11 32 2.8 2.1 5 2 004 h
M2.2X0.45
ISO2X(6HX) 1.9 1.95 3101101026 2.5P 45 - 4 11 32 2.8 2.1 5 2 004 h
M2.3X0.4
ISO2X(6HX) 2.1 2.11 3101101029 2.5P 50 - 4 15 32 2.8 2.1 5 2 004 h
CARBIDE
M2.5X0.45
ISO2X(6HX) 2.2 2.21 3101101032 2.5P 50 - 4 15 32 2.8 2.1 5 2 004 h
M2.6X0.45
ISO2X(6HX) 2.5 2.56 3101101035 2.5P 56 - 5 18 34 3.5 2.7 6 3 004 h
ISO3X(6GX) 2.5 2.56 3101201035 2.5P 56 - 5 18 34 3.5 2.7 6 3 004 h
M3X0.5
7GX 2.5 2.56 3101301035 2.5P 56 - 5 18 34 3.5 2.7 6 3 004 h LONG
ISO2X(6HX)+100 2.5 2.56 3101501035 2.5P 56 - 5 18 34 3.5 2.7 6 3 004 h
ISO2X(6HX) 3.3 3.38 3101101042 2.5P 63 - 7 21 38 4.5 3.4 6 3 004 h
ISO3X(6GX) 3.3 3.38 3101201042 2.5P 63 - 7 21 38 4.5 3.4 6 3 004 h
HAND
M4X0.7
7GX 3.3 3.38 3101301042 2.5P 63 - 7 21 38 4.5 3.4 6 3 004 h TAPS
ISO2X(6HX)+100 3.3 3.38 3101501042 2.5P 63 - 7 21 38 4.5 3.4 6 3 004 h
ISO2X(6HX) 4.2 4.28 3101101049 2.5P 70 - 9 25 39 6 4.9 8 3 004 h
ISO3X(6GX) 4.2 4.28 3101201049 2.5P 70 - 9 25 39 6 4.9 8 3 004 h
EG (STI)
M5X0.8
7GX 4.2 4.28 3101301049 2.5P 70 - 9 25 39 6 4.9 8 3 004 h
ISO2X(6HX)+100 4.2 4.28 3101501049 2.5P 70 - 9 25 39 6 4.9 8 3 004 h
ISO2X(6HX) 5 5.09 3101101055 2.5P 80 - 11 30 45 6 4.9 8 3 004 h
SPECIAL
ISO3X(6GX) 5 5.09 3101201055 2.5P 80 - 11 30 45 6 4.9 8 3 004 h THREADS,
GAUGES
M6X1
7GX 5 5.09 3101301055 2.5P 80 - 11 30 45 6 4.9 8 3 004 h
ISO2X(6HX)+100 5 5.09 3101501055 2.5P 80 - 11 30 45 6 4.9 8 3 004 h
ISO2X(6HX) 6.8 6.85 3101101064 2.5P 90 - 12 35 47 8 6.2 9 3 005 h THREAD
ISO3X(6GX) 6.8 6.85 3101201064 2.5P 90 - 12 35 47 8 6.2 9 3 005 h MILLS
M8X1.25
7GX 6.8 6.85 3101301064 2.5P 90 - 12 35 47 8 6.2 9 3 005 h
ISO2X(6HX)+100 6.8 6.85 3101501064 2.5P 90 - 12 35 47 8 6.2 9 3 005 h
ISO2X(6HX) 8.5 8.6 3101101078 2.5P 100 - 13 39 52.5 10 8 11 3 005 h DIES
ISO3X(6GX) 8.5 8.6 3101201078 2.5P 100 - 13 39 52.5 10 8 11 3 005 h
M10X1.5
7GX 8.5 8.6 3101301078 2.5P 100 - 13 39 52.5 10 8 11 3 005 h
ISO2X(6HX)+100 8.5 8.6 3101501078 2.5P 100 - 13 39 52.5 10 8 11 3 005 h
CENTER
DRILLS
