Spiral Fluted Taps

AL+SP/AL-SP
Intro

MS Material Specific Series
SP
Spiral Fluted Taps for Aluminium
DIN
FEATURES
Material specific for blind hole application.
2.5P
SL HSS-E NI Specific design and NI treatment allow stable and long
THCHT life on Aluminium, Aluminium casting and die-casting.

Recommended Tapping Speeds Depending On Materials
PO
ISO Vc (m/min)
N1 10÷25 +
N2 10÷25 +
ST N3 10÷25 +
N4 10÷25 +
+ 1st choice , suitable
ROLL

DIN-AL+SP/AL-SP
Product Features
CARBIDE AL+SP guarantees consistent tapping even in medium-high speed cutting area, in forged workpieces of light alloys such as aluminum die castings and
aluminum castings.
Featuring an optimized cutting edge design, AL+SP does not produce burrs in minor diameter which usually occours during tapping light alloys. AL+SP
ensure reliability and high quality internal threads.
LONG
Process Data
M6×1
HAND Work-material DIN G-AISi7Mg
TAPS
Tapping length 9mm, blind hole AL+SP
Tapping speed 20 m/min Still working
Competitor's
Hole diameter ø 5.0 product Stopped due to burrs
EG (STI) Machine Vertical machining center
5000 10.000 15.000 20.000 25.000
Lubricant Water soluble oil (x 20) Number of tapped holes
SPECIAL
THREADS,
GAUGES AL+SP Competitor
Internal thread Cross section of internal Internal thread Cross section of internal
threads threads
THREAD
MILLS

DIES

CENTER Compared to competitor, AL+SP assures longer tool life and higher quality internal threads
DRILLS

Technical
info

132
