GP General Purpose Series
Straight Fluted Taps for Miniature Threads SP

FEATURES
Cutting tap for miniature threads
3P
HSS-E SL
THCHT

Recommended Tapping Speeds Depending On Materials
PO
ISO Vc (m/min)
N1 ≤5 +
N2 ≤5 +
N3 ≤5 , ST
N4 ≤5 +
+ 1st choice , suitable
ROLL

JIS-MS+TR
TYPE: ST_005
CARBIDE
K
DCON
LK K
THL LS LONG
LF

HAND
TAPS
TCTR Ø Hole Ø THCHT LF THL LU LS DCON K LK
(tolerance) (mm) (mm) (chamfer) (mm) (mm) (mm) (mm) (mm) (mm) (mm)
S Miniature Code NOF Type Stock
JIS
- 0.31 0.32 GMHRP0.4-3 3P 36 1.5 - 26 3 2.5 6 3 005 f EG (STI)
S0.4X0.1
- 0.4 0.41 GMHRP0.5-3 3P 36 2 - 26 3 2.5 6 3 005 f
S0.5X0.125
- 0.48 0.49 GMHRP0.6-3 3P 36 2.5 - 25 3 2.5 6 3 005 f
S0.6X0.15
- 0.56 0.57 GMHRP0.7-3 3P 36 2.5 - 25 3 2.5 6 3 005 f SPECIAL
THREADS,
S0.7X0.175
- 0.64 0.65 GMHRP0.8-3 3P 36 3 - 25 3 2.5 6 3 005 f
S0.8X0.2 GAUGES
- 0.72 0.73 GMHRP0.9-3 3P 36 3 - 25 3 2.5 6 3 005 f JIS
S0.9X0.225
